Meanwell RS-25-5 Power Supply

5 Volts, 25 Watt Single Output Switching Power Supply from Meanwell

RS-25-5 is a high quality Industrial Grade SMPS fom Meanwell. RS25-5 SMPS is a 15 watt SMPS and gives 12 volts output. Meanwell RS-25-5 switching power supply comes in mesh type casing and is very easy to mount.

Check out our Complete variety of Meanwell SMPS that we have.

We have various types of Load CellsForce SensorFlex Sensor and Pressure Sensor. Check our complete collection of Weigh Sensor and Load cell.

If you are in Nashik you can buy this Electronic Component at our local shop at New CBS, Nashik or you can place order online and get it delivered at your doorstep anywhere in India.

Features of RS25-5 Meanwell SMPS

  • Protections : Short circuit / Overload / Over voltage / Over temperature
  • Universal AC input / Full range
  • Cooling by free air convection
  • LED indicator for power on
  • 100% full load burn-in test
  • No load power consumption<0.5W
  • All using 105  long life electrolytic capacitors
  • Withstand 300 VAC surge input for 5 second
  • High operating temperature up to 70°C
  • Withstand 5G vibration test
  • High efficiency, long life and high reliability
  • Specification for RS25-5 Meanwell Power Supply

    OUTPUT

    Wattage

    Voltage

    Max Current

    25 Watt

    5 Volts

    3 Ampere

    INPUT

    Efficiency

    Frequency Range:

    78.5 %

    47 ~ 63Hz

    PROTECTION

    Overloaded

    Over Volt

    110 ~ 180% Rated Output Power.

    5.75 ~6.75 Volts

    ENVIRONMENT

    Working Temp:

    Working Humidity:

    Storage Temp:

    Vibration:

    -20 ~ +70°C

    20 ~ 90% RH non-condensing

    -40 ~ +85, 10 ~ 95% RH

    10 ~ 500Hz, 5G 10min./1cycle, period for  60min. each along X, Y, Z axes
