Mean Well HDR-30-24 24 V DIN-Rail AC/DC Power Supply

Mean Well HDR-30-24 24 V DIN-Rail AC/DC Power Supply

Mean Well HDR-30-24 DIN-rail AC/DC power supply with 24 V DC, 1.5 A, 36 W output and adjustable voltage.

The Mean Well HDR-30-24 is a DIN-rail AC/DC power supply that converts AC or DC input to a regulated 24 V DC output. It supplies up to 1.5 A and 36 W for control and automation equipment.

Its slim 35 mm plastic housing fits TS-35/7.5 and TS-35/15 rails, helping save cabinet space. The output voltage can be adjusted to suit the load. Short-circuit, overload and overvoltage protection help guard the supply and connected equipment. Free-air convection cooling removes the need for a fan.

Use this supply in building automation, household control systems, industrial control systems and factory automation. Its AC and DC input support makes it useful in varied control panel designs.

DNA stocks Mean Well power supplies for control and automation builds. Browse our Meanwell SMPS range to find a supply that fits your input, output and mounting needs. Check other Meanwell SMPS that we have in stock

If you cannot find the part you need, contact DNA. We support imports and retail or bulk orders across India. Ask us about related items such as IGBTs, diodes, resistors, crystals, digital ICs and development boards. Contact Us

Features of Mean Well HDR-30-24 24 V DIN-Rail AC/DC Power Supply

• Slim housing helps save space in control cabinets
• Mounts on TS-35/7.5 or TS-35/15 DIN rails
• Free-air convection cooling needs no fan
• Short-circuit, overload and overvoltage protection
• Class II isolation and limited power source design
• LED indicates power-on status

Specifications of Mean Well HDR-30-24 24 V DIN-Rail AC/DC Power Supply

• Rated output voltage: 24 V DC
• Rated output current: 1.5 A
• Rated output power: 36 W
• Input voltage: 85–264 VAC or 120–370 VDC
• Output voltage adjustment range: 21.6–29 V
• AC input frequency: 47–63 Hz
• Working temperature: −30 to +70 °C, subject to derating
• Dimensions: 35 × 90 × 54.5 mm (W × H × D)

Applications of Mean Well HDR-30-24 24 V DIN-Rail AC/DC Power Supply

• Household control systems
• Building automation
• Industrial control systems
• Factory automation

Related Links for Mean Well HDR-30-24 24 V DIN-Rail AC/DC Power Supply

• Mean Well HDR-30-24 24 V DIN-Rail AC/DC Power Supply Datasheet

• Other Products from Meanwell SMPS Category

Package Includes

• 1 X Mean Well HDR-30-24 24 V DIN-Rail AC/DC Power Supply
