Hongfa HF33F/005-ZST 5 VDC Subminiature Intermediate Power Relay

  • Stock: Out Of Stock

    Availability: NotInStock priceValidUntil: 2026-12-17

  • Brand: Hongfa
  • SKU: 8716 | DAI138

Availability: NotInStock priceValidUntil: 2026-12-17

  • Rs. 107.38 (inc GST)
    Rs.91.00 + GST
    Qty :

GST Invoice: Available for all purchases; eligible for input tax credit.

Delivery: 2–8 days across India. No MOQ required.

Bulk Orders: Need a larger quantity or item not in stock? Email: dnatechindia [at] gmail.com

Import Service: We import a wide range of electronic components on request.

Hongfa HF33F/005-ZST 5 VDC Subminiature Intermediate Power Relay

Hongfa HF33F/005-ZST is a 5 VDC-coil SPDT relay with PCB terminals, sealed construction and normally open and normally closed contacts.

Hongfa HF33F/005-ZST is a 5 VDC coil relay that switches a circuit through one normally open and one normally closed contact. This Form C SPDT relay gives a design access to both contact paths in one subminiature intermediate power relay. Its plastic-sealed body mounts to a PCB.
AgSnO2 contacts provide the switching interface, while the sealed construction keeps the contact assembly enclosed. Through-hole terminals support direct board installation. The normally open and normally closed contacts have different resistive-load ratings, so choose the contact path and load to match the circuit. This PCB mount relay suits electronic assemblies that need a coil-operated switch with both NO and NC connections.
DNA supplies Hongfa Relay products for electronics buyers in India, including the Hongfa HF33F/005-ZST relay. Browse our Hongfa Relay range for board-level switching designs. Check other Hongfa Relay that we have in stock
If you cannot find a part, contact DNA for import support and retail or bulk orders. We can also help you find related items such as MOSFETs, Transistors, HMI Displays, Humidity & Temperature Sensors, Programmers and Development boards. Contact Us

Features of Hongfa HF33F/005-ZST 5 VDC Subminiature Intermediate Power Relay

  • Form C contact design switches normally open and normally closed paths
  • Plastic-sealed construction encloses the contact assembly
  • AgSnO2 contact material
  • Through-hole PCB terminals support board mounting

Specifications of Hongfa HF33F/005-ZST 5 VDC Subminiature Intermediate Power Relay

  • Nominal coil voltage: 5 VDC
  • Coil pick-up voltage: 3.75 VDC max. for standard coil
  • Coil drop-out voltage: 0.25 VDC min. for standard coil
  • Coil resistance: 55 Ω ±10% for standard 5 V coil at 23°C
  • Coil power: Approximately 450 mW for standard coil
  • Contact rating: Normally open 5 A at 250 VAC or 30 VDC, or 10 A at 125 VAC
  • Maximum switching voltage: 250 VAC / 30 VDC
  • Body dimensions: 20.5 × 10.2 × 15.7 mm

Related Links for Hongfa HF33F/005-ZST 5 VDC Subminiature Intermediate Power Relay

Package Includes

  • 1 X Hongfa HF33F/005-ZST 5 VDC Subminiature Intermediate Power Relay
Extra Information
Country of Origin China
Imported By ElectroSource Private Limited
