IRG4PC40UD Ultra-Fast CoPack IGBT TO-247 Package

IRG4PC40UD: 600V Ultra-Fast CoPack IGBT for High Frequency Power Switching

The IRG4PC40UD is a 600 V Ultra-Fast IGBT with CoPack diode, designed for high-frequency power switching applications. It combines a rugged IGBT and an ultra-fast recovery anti-parallel diode in a single TO-247 package, optimized for soft-switching resonant and hard-switching circuits up to 60 kHz. With a collector current rating of 37 A and low switching losses, it is ideal for inverters, welding equipment, induction heating, and other demanding industrial applications.

DNA is a trusted supplier of audio and power transistors in India, offering retail and bulk purchase options. We stock popular Electronic components like BJTs, MOSFETs, IGBTs, and rectifier diodes, available for fast dispatch across India.

Can’t find the exact transistor or Electronic Component? Our team can help you source it, click here to contact us.

Features of IRG4PC40UD IGBT

• 600 V Ultra-Fast IGBT with CoPack diode
• Low V_CE(on) for reduced conduction loss
• Optimized for frequencies from 8 kHz to 60 kHz
• High-speed switching and soft recovery diode
• TO-247 package with excellent thermal handling
• Low tail current for improved efficiency
• Rugged construction for industrial environments

Specifications of IRG4PC40UD IGBT

• IGBT Type: Ultra-Fast CoPack
• Collector-Emitter Voltage (V_CES): 600 V
• Collector Current (I_C): 37 A (Tc = 25°C)
• Pulsed Collector Current (I_CM): 74 A
• Gate-Emitter Voltage (V_GE): ±20 V
• Switching Frequency Range: 8 kHz to 60 kHz
• Collector Dissipation (P_D): 208 W
• Total Gate Charge (Q_g): 155 nC
• Package: TO-247

Applications of IRG4PC40UD IGBT

• Switch-mode power supplies (SMPS)
• High-frequency induction heating circuits
• Inverter-based welding equipment
• Resonant and hard-switching power converters
• Motor control and UPS systems

Related Links

• IRG4PC40UD Datasheet (PDF)
• Browse More Transistors & Diodes

Package Include

• 1 x IRG4PC40UD Ultra-Fast CoPack IGBT (TO-247)
