KA78R12 12V Low Dropout Voltage Regulator TO‑220 Package

KA78R12: 12V Low Dropout Voltage Regulator for Precision Power Supply Applications

The KA78R12 is a 12V Low Dropout Voltage Regulator that offers precise and stable output with low dropout performance, making it suitable for a wide range of regulated DC power applications. Designed to provide a fixed 12 V output with excellent line and load regulation, the KA78R12 features built-in current limiting, thermal shutdown, and safe area compensation. It is ideal for microcontroller systems, audio/visual equipment, and other electronics requiring a regulated 12 V source.

DNA is a trusted supplier of MOSFETs and power transistors in India, offering retail and bulk purchase options. We stock popular electronic components like BJTs, MOSFETs, and rectifier diodes, available for fast dispatch across India.

Can’t find the exact transistor or Electronic Component? Our team can help you source it,  click here to contact us.

Features of KA78R12 Voltage Regulator

• Fixed 12V output voltage
• Low dropout voltage (typically 0.5V to 1.0V)
• Built-in current limiting and thermal protection
• Internal short-circuit protection
• Excellent line and load regulation
• Suitable for high-accuracy voltage regulation applications

Specifications of KA78R12 Voltage Regulator

• Output Voltage: 12 V
• Output Current: Up to 1 A
• Dropout Voltage: ~1.0 V typical
• Quiescent Current: 5 mA (typical)
• Line Regulation: 0.01%/V (typical)
• Load Regulation: 0.3% (typical)
• Thermal Shutdown and Current Limit Features
• Package: TO‑220 (3-pin)

Applications of KA78R12 Voltage Regulator

• Power supplies for microcontroller systems
• Audio/visual equipment
• Voltage regulation in embedded and control systems
• Industrial automation
• Consumer electronics power modules

Related Links

• KA78R12 Datasheet (PDF)
• Browse More Power Components

Package Include

• 1 × KA78R12 Voltage Regulator (TO‑220)
