MAX30102 Heart Rate and Pulse Oximeter Sensor Module

MAX30102 Heart Rate and Pulse Oximeter Sensor Module

The MAX30102 is an integrated pulse oximetry and heart-rate monitor module. It includes internal LEDs, photodetectors, optical elements, and low-noise electronics with ambient light rejection. The MAX30102 provides a complete system solution to ease the design-in process for mobile and wearable devices.

The MAX30102 operates on a single 1.8V power supply and a separate 3.3V power supply for the internal LEDs. Communication is through a standard I2C-compatible interface. The module can be shut down through software with zero standby current, allowing the power rails to remain powered at all times.

DNA solutions, Nashik has various types of Sensor Module's. Check out our complete collection of  Sensor Module's.

• Heart-Rate Monitor and Pulse Oximeter Sensor in LED Reflective Solution


• Tiny 5.6mm x 3.3mm x 1.55mm 14-Pin Optical Module


• Ultra-Low Power Operation for Mobile Devices


• Fast Data Output Capability-High Sample Rates


• -40°C to +85°C Operating Temperature Range


Specifications of MAX30102 Heart Rate and Pulse Oximeter Sensor Module

• Module Type: Heart Rate and Pulse Oximeter Sensor


• Sensor: MAX30102


• Supply Voltage (VDD): 1.8V (logic), 3.3V (LED)


• Operating Current: Low Power: 600 µA (typical)


• LED Current: Programmable from 0 to 50 mA


• Data Output Rate: Programmable (50-4000 samples per second)


Package Includes

• 1 x MAX30102 Heart Rate and Pulse Oximeter Sensor Module
