ULN2002 Darlington Transistor DIP IC

ULN2002 Darlington Transistor DIP IC

The ULN2002 is a high-voltage, high-current Darlington transistor array designed for interfacing between TTL/CMOS logic and inductive or high-power loads. It consists of seven independent NPN Darlington pairs, each capable of driving up to 500 mA and withstanding voltages up to 50V. Integrated clamp diodes protect the drivers from back-EMF, making it ideal for controlling relays, stepper motors, lamps, and solenoids. The ULN2002 is typically used in applications requiring reliable and efficient switching of medium to high power devices directly from logic-level signals.

DNA solutions, Nashik has various types of Transistor's. Check out our complete collection of Transistor's.

• 7 NPN Darlington pair channels

• TTL and 5V CMOS input logic compatible

• 500 mA output current per channel

• 50V output voltage capability

• Built-in fly back diodes for inductive load protection

Specifications of ULN2002 Darlington Transistor DIP IC

• Supply Voltage: Not required

• Output Voltage: 50V

• Output Current: 500 mA

• Total Package Current: 2.5 A

• Input Voltage: TTL/5V logic compatible

• Package Type: DIP-16

• Operating Temp Range: –20°C to +85°C

Applications of ULN2002 Darlington Transistor DIP IC

• Driving relays and solenoids

• Stepper motor driver

• LED and display drivers

Package Includes

      1 x ULN2002 Darlington Transistor DIP
