ULN2803APG 8 Darlington Transistor Arrays IC DIP‑18 Package

ULN2803APG 8 Darlington Transistor Arrays IC DIP‑18 Package

The ULN2803APG 8 Darlington Transistor Arrays IC DIP‑18 Package is an 8-channel Darlington sink driver comprising high–voltage, high–current NPN transistor pairs in a DIP-18 package. Each channel can sink up to 500 mA at voltages up to 50 V, and includes built-in clamp diodes for inductive load protection, making it ideal for drivers, relays, lamps, and motor controls.

DNA Solutions, Nashik stocks various transistor arrays and driver ICs. Explore our full range of Transistor Arrays IC's.

Features of ULN2803APG 8 Darlington Transistor Arrays IC DIP‑18 Package

• 8 NPN Darlington pairs with common emitter

• Each channel sinks up to 500 mA at ≤ 50 V

• Integral clamp diodes for inductive load protection

• Compatible with TTL/CMOS logic inputs via 2.7 kΩ base resistors

• Available in through-hole DIP‑18 package for easy prototyping

Specifications of ULN2803APG 8 Darlington Transistor Arrays IC DIP‑18 Package

• Number of Channels: 8

• Current Rating: 500 mA per channel

• Voltage Rating V_CEO: 50 V min

• Package: DIP‑18, through‑hole, 7.62 mm pitch

• Operating Temperature: –40 °C to +85 °C

Applications of ULN2803APG 8 Darlington Transistor Arrays IC DIP‑18 Package

• Driving relays, solenoids & motors

• LED or incandescent lamp drivers

• Stepper motor or display drivers

• Relay interface for microcontroller digital outputs

Package Includes

    1 × ULN2803APG 8 Darlington Transistor Arrays IC (DIP‑18)
