6P plug 6 Pin JST-XH Double Side Female Polarized Header Wire

6P plug 6 Pin JST-XH Double Side Female Polarized Header Wire

The 6-pin JST-XH connector is a widely used connector type in electronic and electrical applications. It features a polarized design to ensure proper alignment and secure connections. The double-sided female header provides additional versatility for connecting multiple devices or components.

DNA solutions, Nashik has various types of Connectors. Check out our complete collection of Connectors.

• Pin Count: 6 pins

• Connector Type: JST-XH, female header, double-sided

• Polarization: Built-in polarization to prevent reverse connection

• Pitch: 2.5 mm (standard for JST-XH connectors)

• Durable Build: High-quality plastic housing and metal pins for durability

• Compact Size: Ideal for space-constrained applications

• Easy Assembly: Simple to crimp and connect to wires

• Versatile: Suitable for both low-power and signal applications

Specifications of 6P plug 6 Pin JST-XH Double Side Female Polarized Header Wire

• Current Rating: Up to 3A per pin

• Voltage Rating: Typically 250V AC/DC

• Temperature Range: -25°C to +85°C

• Contact Resistance: ≤ 10 mΩ

• Insulation Resistance: ≥ 1000 MΩ at 500V DC

• Wire Gauge: Supports 26–22 AWG wires

• Dimensions: Standard size according to JST-XH specifications

Applications of 6P plug 6 Pin JST-XH Double Side Female Polarized Header Wire

• Consumer Electronics

• Automotive

• Industrial Automation

• Home Appliances

• Robotics

Package Includes

      1 x 6P plug 6 Pin JST-XH Double Side Female Polarized Header Wire
