Product Images are shown for illustrative purposes only and may differ from actual product.

CD4052 CMOS 4-Channel Analog Multiplexer And Demultiplexer 16PIN IC

Write a review | 1 reviews

Stock: 20
Availability: InStock priceValidUntil: 2026-11-27
SKU: 7604 | DAH325

Rs. 16.52 (inc GST)
Rs.14.00 + GST
Qty : Qty Qty

GST Invoice: Available for all purchases; eligible for input tax credit.

Delivery: 2–8 days across India. No MOQ required.

Bulk Orders: Need a larger quantity or item not in stock? Email: dnatechindia [at] gmail.com

Import Service: We import a wide range of electronic components on request.

Description

CD4052 CMOS 4-Channel Analog Multiplexer and Demultiplexer IC

CD4052 4-Channel Mux/Demux with low ON resistance and low leakage current, operating voltage 3V to 20V.

The CD4052 CMOS 4-Channel Analog Multiplexer and Demultiplexer IC is a versatile device that functions as a 4:1 multiplexer and a 1:4 demultiplexer. It features low ON resistance of 125 ohms at 18V and a minimal OFF leakage current of ±100pA, ensuring reliable signal integrity. This IC operates within a voltage range of 3V to 20V and is ideal for both analog and digital signal applications.

Engineered for efficiency, the CD4052 CMOS 4-Channel Analog Multiplexer and Demultiplexer IC supports low power consumption, making it suitable for low-power applications. Its operating temperature range of -55 to 125 °C allows for use in various environmental conditions. This IC is perfect for applications in analog and digital multiplexing, A/D and D/A conversion, and programmable logic circuits.

For ease of integration, consider using the CD4052 CMOS 4-Channel Analog Multiplexer and Demultiplexer IC with a 16 pin DIP IC base. Explore its capabilities and enhance your electronic projects with this reliable multiplexer/demultiplexer.

At DNA, we offer a wide range of 4000 Series IC's from trusted brands. Explore the CD4052 CMOS 4-Channel Analog Multiplexer and Demultiplexer IC and other products in the 4000 Series IC's category for your electronic needs. Check other 4000 Series IC's that we have in stock.

If you are searching for specific electronic components, reach out to us. We can assist you in finding parts or import them if necessary. We support both retail and bulk orders. Consider browsing related items like Microcontrollers, Analog ICs, IGBTs, Hongfa Relays, and DC to DC Converter Modules. Contact Us.

Features of CD4052 CMOS 4-Channel Analog Multiplexer and Demultiplexer IC

Used as 4:1 Mux and 1:4 Demux
Supports ≤ 20 Vp-p Analog Voltage
Supports 3-20 V Digital Voltage
Low ON resistance, 125 Ω at 18V
Low OFF leakage Current, ±100pA at 18V
Max input current of 1uA at 18V
Operating Temperature, -55 to 125 °C

Specification of CD4052 CMOS 4-Channel Analog Multiplexer and Demultiplexer IC

Functionality: Dual 4-channel multiplexer/de multiplexer
Analog/Digital Compatibility: Suitable for both analog and digital signals
Voltage Range: Operates over a wide voltage range
Leakage Current: Very low leakage current in both on and off states
Signal Range: Can pass signals up to the full supply voltage range
Power Consumption: Low power dissipation, ideal for low-power applications

Applications of CD4052 CMOS 4-Channel Analog Multiplexer and Demultiplexer IC

Analog multiplexing
Digital multiplexing
A/D conversion
D/A conversion
Programmable logic circuits

Package Includes

1 X CD4052 CMOS 4-Channel Analog Multiplexer and Demultiplexer IC 16PIN IC
