DPDT Slide Switch

Center Off 3 way 6 Pin DPDT Slide Switch with ON - OFF - ON contact

This is a Double Pole Double Throw (DPDT) 3 way Slide switch with 6 terminals and a vertical handle with 3 Positions having center OFF.

Widely used to control operation of many small power electronic projects, including volume and other controls for audio video, dimmer controls for lights, etc.

Specifications of 3 Way DPDT Slide Switch

• Product Name : Vertical Slide Switch

• Model No : CS 23F25

• Position : 3 (On - OFF -ON)

• Pins Design : 6 Pins ( Double Rows )

• Rating : DC 30 Volts, 0.5 Ampere

• Contacts Resistance : 30MΩ

• Insulation Resistance : 100MΩ

• Minimum Load : DC 500V

• Dielectric Strengths : AC 500V / 1 minute

• Life Test : 10000 cycles/ minute

• Mounting Hole Dia : 2mm/ 5/64"

• Overall Size : 23.3 x 7.4 x 18mm/  0.63" x 0.26" x 0.71" (L*W*H)

• Material : Plastic and Metal
