DRV8212DRLR Bipolar Motor Driver NMOS IC

Texas Instruments DRV8212 Bipolar Motor Driver IC

DRV8212DRLR IC for driving brushed DC motors with low RDS(on) and up to 1.2 A output current.

The Texas Instruments DRV8212 Bipolar Motor Driver IC is a compact solution for driving brushed DC motors and solenoids. This efficient H-bridge motor driver offers low on-resistance NMOS transistors, supporting up to 1.2 A continuous output current. With a wide supply voltage range of 4.5 V to 11 V, it suits battery-powered and space-constrained applications. The integrated protection features include thermal shutdown and undervoltage protection, ensuring reliable operation in various environments.

Ideal for applications like battery-powered toys, printers, and home automation actuators, the DRV8212 Bipolar Motor Driver IC excels in versatility and efficiency. Its compact 8-pin HVSSOP package makes it easy to integrate into your designs. The low power standby mode enhances energy efficiency, making this IC a smart choice for modern electronics.

Explore the capabilities of the Texas Instruments DRV8212 Bipolar Motor Driver IC and elevate your project with reliable motor control. With its robust design, this motor driver is perfect for consumer electronics and robotics, ensuring smooth operation and performance.

Explore the range of Motor Driver Modules at DNA Solutions. The Texas Instruments DRV8212 Bipolar Motor Driver IC offers reliable performance for your projects. Check other Motor Driver Modules that we have in stock.

At DNA, we cater to the needs of Indian electronics buyers. If you can't find specific parts, feel free to reach out. We can import items not in stock and support both retail and bulk orders. Check out related items like HMI Displays, Hongfa Relays, and Microcontrollers. Contact Us.

Features of Texas Instruments DRV8212 Bipolar Motor Driver IC

• Low-RDS(on) NMOS H-Bridge motor driver
• Supports up to 1.2 A continuous current
• Wide operating voltage range: 4.5 V to 11 V
• Integrated protection: thermal shutdown and undervoltage
• Compact 8-pin HVSSOP package

Specification of Texas Instruments DRV8212 Bipolar Motor Driver IC

• Model: DRV8212DRLR
• Motor Type: Brushed DC Motor
• Continuous Output Current: 1.2 A
• Peak Output Current: 3.7 A
• Supply Voltage: 4.5 V to 11 V
• Interface: IN1/IN2 Control
• Package: 8-pin HVSSOP

Applications of Texas Instruments DRV8212 Bipolar Motor Driver IC

• Battery-powered toys and robots
• DC motor control in consumer electronics
• Printers and scanners
• Home automation actuators
• Solenoid drivers

Package Includes

• 1 X Texas Instruments DRV8212 Bipolar Motor Driver IC
