Product Images are shown for illustrative purposes only and may differ from actual product.

2N3906 Small Signal PNP Transistor

Write a review | 2 reviews

Stock: 25
Availability: InStock priceValidUntil: 2026-06-06
SKU: 687 | DAA281

Rs. 2.36 (inc GST)
Rs.2.00 + GST

Qty :
Qty Qty

GST Invoice: Available for all purchases; eligible for input tax credit.

Delivery: 2–8 days across India. No MOQ required.

Bulk Orders: Need a larger quantity or item not in stock? Email: dnatechindia [at] gmail.com

Import Service: We import a wide range of electronic components on request.

Description

2N3906 Small Signal PNP Transistor

The 2N3906 is a commonly used PNP bipolar junction transistor intended for general purpose low-power amplifying or switching applications.

It is designed for low electric current and power and medium voltage, and can operate at moderately high speeds.

The 2N3906 transistor has a collector current of 200 mA, collector-base and collector-emitter voltages of 40 V, for power dissipation of 300 mW. Its transition frequency Ft is 250 MHz, with a beta of at least 100.

Features of 2N3906 PNP Transistor

Package type TO-92
V_CBO Collector-Base Voltage (I_E=0) -60 V
V_CEO Collector-Emitter Voltage (I_B=0) -40 V
V_EBO Emitter-Base Voltage (I_C=0) -6 V
I_CCollector Current -200 mA
P_tot Total Dissipation at TC=25oC 625 mW
T_stg Storage Temperature -65 to 150 C
T_j Max. Operating Junction Temperature 150 C

Applications of 2N3906 PNP Transistor

Well Suitable for TV and home Appliance equipment.
Small load switch transistor with high gain and low saturation voltage

Extra Information
Country of Origin	China
Imported By	ElectroSource Private Limited
