  • IR2153 Self-Oscillating Half Bridge Driver

Product Images are shown for illustrative purposes only and may differ from actual product.

IR2153 Self-Oscillating Half Bridge Driver

  • Stock: 4
  • SKU: 0634 | DAA146
  • Rs. 84.96 (inc GST)
    Rs.72.00 + GST

    Qty :

GST Invoice on all Purchase. So you will be eligible to take input tax credit.

IF component not in Stock or require more quantity or want to buy in bulk e-mail us your requirements on: dnatechindia "at" gmail.com.

Shipping : Due to Covid-19 situation delivery will be affected. Delivery period due to covid-19 issue will be from 4 - 12 days depending upon your location.

IR2153 Self-Oscillating Half Bridge Driver

The IR2153 is an improved version of the popular IR2155 and IR2151 gate driver ICs, and incorporates a high voltage half bridge gate driver with a front end oscillator similar to the industry standard CMOS 555 timer.

The IR2153 provides more functionality and is easier to use than previous ICs. A shutdown feature has been designed into the CT pin, so that both gate driver outputs can be disabled using a low voltage control signal. In addition, the gate driver output pulse widths are the same once the rising under voltage lockout threshold on VCC has been reached, resulting in a more stable profile of frequency vs time at startup. Noise immunity of IR2153 Half Bridge Driver has been improved significantly, both by lowering the peak di/dt of the gate drivers, and by increasing the under voltage lockout hysteresis to 1V. Finally, special attention has been payed to maximizing the latch immunity of the device, and providing comprehensive ESD protection on all pins.

Features of IR2153 Self-Oscillating Half Bridge Driver

  • Integrated 600V half-bridge gate driver

  • 15.6V zener clamp on Vcc

  • True micropower start up

  • Tighter initial deadtime control

  • Low temperature coefficient deadtime

  • Shutdown feature (1/6th Vcc) on CT pin

  • Increased under voltage lockout Hysteresis (1V)

  • Lower power level-shifting circuit

  • Constant LO, HO pulse widths at startup

  • Lower di/dt gate driver for better noise immunity

  • Low side output in phase with RT

  • Internal 50nsec (typ.) bootstrap diode (IR2153D)

  • Excellent latch immunity on all inputs and outputs

  • ESD protection on all leads
