Product Images are shown for illustrative purposes only and may differ from actual product.
8S 20Amp Lithium Polymer BMS Battery Protection Board
- Stock: Out Of Stock
- SKU: 1968 | DAB398
-
Rs. 1,572.35 (inc GST)
Rs.1,332.50 + GSTQty :
| Also Available: PMS5003 PM2.5 AIR QUALITY SENSOR BY PLANTOWER in Stock |
GST Invoice: Available for all purchases; eligible for input tax credit.
Delivery: 2–8 days across India. No MOQ required.
Bulk Orders: Need a larger quantity or item not in stock? Email: dnatechindia [at] gmail.com
Import Service: We import a wide range of electronic components on request.
8S 20A Lithium Polymer BMS Battery Protection Board
PCM without balance + balance board = PCM with balance function
Two Version
- 8S 20A no balance : just a 8S BMS board, without balance function.
- 8S 20A with balance : 8S BMS board add a 8S balance board
Aplications of 8S 20A Lithium Polymer BMS Battery Protection Board
- 8S lipo batteries rechargables
- Shilly-car
- Drift car
- Electric cars
Features Of 8S 20A Lithium Polymer BMS Battery Protection Board
- High-accuracy voltage detection circuit.
- Terminal of the charger using high voltage device.
- Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit).
- MOS transistor can control the battery charge and discharge.
- Low standby current consumption.
Parameters Of 8S 20A Lithium Polymer BMS Battery Protection Board
- Over Charge voltage : 4.25v±0.05v
- Over Discharge voltage : 2.5v±0.02v
- Over current : 100A
- Continuous current : 20A
- Short Cut : Protectable, Charge can repair
- There are 10 singal wires, if you make 4S battery pack, you can just connect 4 wires.
- it max can make 10S battery pack.
This board can use as 4S/20A, 5S/20A, 6S/20A, 7S/20A, 8S/20A, 9S/20A, 10S/20A PCM.
- 4S/20A charge voltage is 4.2V*4=16.8V
- 5S/20A charge voltage is 4.2V*5=21V
- 6S/20A charge voltage is 4.2V*6=25.2V
- 7S/20A charge voltage is 4.2V*7=29.4V
- 8S/20A charge voltage is 4.2V*8=33.6V
- 9S/20A charge voltage is 4.2V*9=37.8V
- 10S/20A charge voltage is 4.2V*10=42V
Note :There are two connections ways :
- Charge/discharge with different ports:
"P-" is the discharge negative end,"P+"is the discharge positive end.
" C-" is the charge negative end, "P+" is the charge positive end. Charge current is 10A;Discharge current is 20A.
- Charge/discharge with the same ports:
" C- " is the charge/discharge negative end.
" P+ "is the charge/discharge positive end .
Charge/discharge current is
