LM555 Timer IC

LM555 Timer IC

LM555 Timer IC for accurate timing; Operates in astable and monostable modes; Output can source or sink 200 mA.

The LM555 Timer IC is a reliable component for generating precise time delays and oscillations. It operates in both astable and monostable modes, allowing for versatile applications in timing circuits. With the ability to handle up to 200 mA, the LM555 Timer IC drives TTL circuits effortlessly. This feature makes it suitable for a variety of electronic projects, from simple timers to complex oscillators.

In the time delay mode, the timing is controlled by a resistor and capacitor, ensuring accuracy across a wide range of timing intervals. The LM555 Timer IC boasts temperature stability better than 0.005% per °C, making it ideal for environments with fluctuating temperatures. Whether you are a hobbyist or a professional engineer, this IC provides the stability and reliability needed for your designs.

Explore the potential of the LM555 Timer IC in various applications, including pulse width modulation, signal generation, and timer circuits. Its direct compatibility with TTL logic makes it a favored choice for many electronic projects, ensuring seamless integration into your designs.

At DNA, we offer the reliable LM555 Timer IC from trusted manufacturers in the Misc Digital IC's category. Explore our selection to find the right components for your projects. Check other Misc Digital IC's that we have in stock.

If you are looking for specific electronic components, DNA has you covered. We can help you source IGBTs, Microcontrollers, MOSFETs, Sensors, and more. If we don't have it in stock, we can import it for you. Contact Us.

Features of LM555 Timer IC

• Direct replacement for SE555/NE555
• Operates in astable and monostable modes
• Adjustable duty cycle
• Output can source or sink 200 mA
• Temperature stability better than 0.005% per °C.

Specification of LM555 Timer IC

• Supply Voltage: 4.5V to 15V
• Timing Range: Microseconds to Hours
• Output Current: 200 mA
• Frequency Stability: Better than 0.005% per °C.

Applications of LM555 Timer IC

• Pulse width modulation
• Signal generation
• Timer circuits
• Oscillator circuits
• Frequency modulation.

Package Includes

• 1 X LM555 Timer IC
