SML4744A-E3 ZENER DIODE

SML4744A-E3 ZENER DIODE

The SML4744A-E3 is a 1-watt, axial-leaded Zener diode designed to provide reliable voltage regulation and protection in electronic circuits. With a Zener voltage of 15V, it ensures precise voltage clamping and stable operation in both linear and switching power supplies. Encased in a DO-204AL (DO-41) glass package, this diode is rugged, moisture-resistant, and ideal for through-hole PCB mounting. The diode features tight voltage tolerance, low leakage current, and high surge capability, ensuring long-term durability and accurate voltage reference. Manufactured by Vishay, the SML4744A-E3 meets RoHS and REACH compliance, making it suitable for environmentally regulated applications.

DNA solutions, Nashik has various types of DIODE's. Check out our complete collection of DIODE's.

• Silicon planar Zener diode

• High reliability and stability

• Low leakage current

• Glass passivated junction

• Power dissipation up to 1 W

• Wide voltage selection: 3.3 V to 75 V (for series)

• DO-41 axial lead package

Specifications of SML4744A-E3 ZENER DIODE

• Zener Voltage (Vz): 15 V

• Tolerance: ±5%

• Power Dissipation (Ptot): 1 W

• Test Current (Iz): 17 mA

• Package Type: DO-41

• Mounting Style: Through Hole

• Zener Impedance (Zz): 17 Ω (at Izt)

Applications of SML4744A-E3 ZENER DIODE

• Voltage regulation and reference

• Overvoltage protection

• Switch mode power supplies

• Consumer electronics

• Automotive electronics

Package Includes

      1 x SML4744A-E3 ZENER DIODE
