Bedook FM18-T015P-C31P2 Diffuse Photoelectric Sensor

  • Stock: 10

    Availability: InStock priceValidUntil: 2026-12-21

  • Brand: Bedook
  • SKU: 7629 | DAH483

Availability: InStock priceValidUntil: 2026-12-21

  • Rs. 1,741.01 (inc GST)
    Rs.1,475.43 + GST
    Qty :
  • GST InvoiceWith every order
  • Delivery Across IndiaUsually 2–8 days
  • Bulk OrdersAsk for a quote
  • Import & SourcingComponents imported on request

Bedook FM18-T015P-C31P2 Diffuse Photoelectric Sensor

Bedook FM18-T015P-C31P2 diffuse photoelectric sensor with 10–30 VDC operation, <2 ms response time and IP66 protection.

Bedook FM18-T015P-C31P2 is a diffuse photoelectric sensor that detects objects by sensing light reflected from their surfaces. Its infrared light source uses an 880 nm wavelength, and the sensor operates from a 10–30 VDC supply.
A response time below 2 ms and a 500 Hz switching rate help control systems react to object movement. A single-turn potentiometer lets users adjust light immunity, while IP66 protection helps limit dust and water ingress. The sensor has an M18 threaded structure for installation in a suitable mounting point. The exact sensing distance and output configuration for this part number are not confirmed, so check them before selecting it for a specific setup.
Find Bedook sensing parts at DNA, your retailer for Temperature and Humidity Sensor products. Browse available stock and choose components that fit your design needs. Check other Temperature and Humidity Sensor that we have in stock
For Indian electronics buyers, DNA can help source parts that are hard to find. Ask about import support and retail or bulk orders. You can also explore Digital IC, HMI Display, Microcontroller and Power Supply products. Contact Us

Features of Bedook FM18-T015P-C31P2 Diffuse Photoelectric Sensor

  • Detects objects through diffuse reflected-light sensing
  • Uses an infrared light source
  • Includes single-turn light-immunity adjustment
  • M18 threaded structure supports panel mounting
  • Yellow indicator shows operating status

Specifications of Bedook FM18-T015P-C31P2 Diffuse Photoelectric Sensor

  • Detection method: Diffuse
  • Operating voltage: 10–30 VDC
  • Response time: <2 ms
  • Switching frequency: 500 Hz
  • Light resistance: <5000 lux
  • Ambient temperature: −25 to 55 °C
  • Ambient humidity: 35–85%
  • Ingress protection: IP66

Related Links for Bedook FM18-T015P-C31P2 Diffuse Photoelectric Sensor

Package Includes

  • 1 X Bedook FM18-T015P-C31P2 Diffuse Photoelectric Sensor
Extra Information
Country of Origin China
Imported By ElectroSource Private Limited
