L297 Stepper Motor Driver Controller 20 Pin DIP IC

L297 Stepper Motor Driver Controller 20 Pin DIP IC

The L297 is a stepper motor controller IC designed to interface with power drivers like the L298 or L293 for precise control of bipolar and unipolar stepper motors. It provides all the logic required for stepper motor control, including step clock input, direction control, and enable signals. Operating in full, half, or wave drive modes, it ensures smooth motor operation. Housed in a 20-pin DIP package, it is ideal for motion control applications in CNC, robotics, and automation systems.

DNA solutions, Nashik has various types of Controller IC's. Check out our complete collection of Controller IC's.

• Controls bipolar or unipolar stepper motors

• Compatible with L298, L293 driver ICs

• Selectable drive modes: full, half, and wave

• Step clock and direction control inputs

• Enable, sync, and reset functionalities

Specifications of L297 Stepper Motor Driver Controller 20 Pin DIP IC

• Supply Voltage: 4.75V – 5.25V

• Operating Frequency: Up to 25 kHz

• Control Modes: Full, Half, Wave Drive

• Output Current: Logic level output

• Input Logic Level: TTL/CMOS Compatible

• Package Type: DIP-20

Applications of L297 Stepper Motor Driver Controller 20 Pin DIP IC

• Robotic arms and automation systems

• Stepper motor-based positioning systems

• Camera sliders and precision control setups

• Mechatronics and embedded control projects

Package Includes

      1 x L297 Stepper Motor Driver Controller 20 Pin DIP IC
