Features

• High Performance RISC CPU


• Flexible Oscillator Structure


• Precision 16MHz Internal Oscillator Block


• Four Crystal Modes up to 64MHz


• Extreme Low-power Management with nanoWatt XLP™


• Two External Clock Modes up to 64MHz


• 100nA, Typical Sleep Mode


• 500nA, Typical Watchdog Timer


• 500nA at Typical 32kHz Timer1 Oscillator


• 4X Phase Lock Loop (PLL)


• Secondary Oscillator Using Timer1 at 32kHz


• Fail-safe Clock Monitor, Allows for Safe Shutdown If Peripheral Clock Stops


• Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)


• Programmable Brown-out Reset (BOR)


• Extended Watchdog Timer (WDT) with On-chip Oscillator and Software Enable


• Programmable Code Protection


• In-circuit Serial Programming™ (ICSP™) via Two Pins


• Two-speed Oscillator Start-up


• Full 5.5V Operation


• Self-reprogrammable Under Software Control

Applications

Consumer Electronics, Computers & Computer Peripherals, Automotive
