STP80NF55-08 Power MOSFET

STMicroelectronics STP80NF10 Power MOSFET for DC-DC Converters

STP80NF10 MOSFET designed for low gate charge and high efficiency. Max VDS 100V, ID 80A, and Ptot 300W.

The STMicroelectronics STP80NF10 Power MOSFET is engineered for high-efficiency isolated DC-DC converters, making it ideal for telecom and computer applications. This MOSFET minimizes input capacitance and gate charge, ensuring optimal performance in various electronic circuits. With a maximum drain-source voltage of 100V and continuous drain current of 80A, it meets the demands of modern electronic systems.

The STMicroelectronics STP80NF10 Power MOSFET features exceptional dv/dt capability and is 100% avalanche tested, ensuring reliability in critical applications. Its application-oriented characterization and robust thermal performance, with a maximum junction temperature of 175°C, provide confidence in its use across various environments. This component is perfect for projects requiring low gate charge drive.

Explore the benefits of the STMicroelectronics STP80NF10 Power MOSFET in your designs. Its versatility makes it suitable for a wide range of applications, including power supplies and motor control systems. Experience efficiency and reliability with this advanced MOSFET, an essential part of your electronic components toolkit.

Discover quality in MOSFET & IGBT components at DNA Solutions. The STMicroelectronics brand offers reliable performance. Check other MOSFET & IGBT that we have in stock.

At DNA, we cater to all your electronic component needs. If you are looking for specific parts like IGBT, Connectors, or Microcontrollers, we can help. We also support imports for hard-to-find items. Contact Us.

Features of STMicroelectronics STP80NF10 Power MOSFET

• Exceptional dv/dt capability
• 100% Avalanche tested
• Application oriented characterization

Specification of STMicroelectronics STP80NF10 Power MOSFET

• VDS Drain-source voltage (VGS = 0) 100V
• VGS Gate- source voltage ±20V
• ID Drain current (continuous) at TC = 25 °C 80A
• Ptot Total dissipation at TC = 25 °C 300W
• Tj Operating junction temperature -55 to 175°C

Applications of STMicroelectronics STP80NF10 Power MOSFET

• DC-DC converters
• Telecom power supplies
• Computer power management
• Motor control systems

Related Links for STMicroelectronics STP80NF10 Power MOSFET for DC-DC Converters

• Other Products from MOSFET & IGBT Category

Package Includes

• 1 X STMicroelectronics STP80NF10 Power MOSFET
