TDA2030 Hi-Fi Audio Amplifier

The UTC TDA2030 is a monolithic audio power amplifier integrated circuit.

TDA2030 is 18 watt  Hi-Fi Audio Amplifier. The TDA2030 Audio amplifier  provides high output current and has very low harmonic and cross-over distortion. Further the device incorporates a short circuit protection system comprising an arrangement for automatically limiting the dissipated power so as to keep the working point of the output transistors within their safe operating area. A conventional thermal shut-down system is also included.

Features of TDA2030

• Very low external component required.

• High current output and high operating voltage.

• Low harmonic and crossover distortion.

• Built-in Over temperature protection.

• Short circuit protection between all pins.

• Safety Operating Area for output transistors.

• Supply Voltage Vs : ±18 V

• Input Voltage VIN : Vs V

• Differential Input Voltage VI(DIFF) : ±15 V

• Peak Output Current(internally limited) I OUT : 3.5 A

• Total Power Dissipation at Tc=90°C PD : 20 W

• Junction Temperature TJ : -40~+150 °C

• Storage Temperature TSTG : -40~+150 °C
