DS1307 RTC

DS1307 Real Time Clock IC

DS1307 RTC for accurate timekeeping with I2C interface, 56 bytes NV SRAM, and low power consumption.

The DS1307 Real Time Clock IC is designed for precise timekeeping in electronic projects. It features a low-power design that includes a full binary-coded decimal (BCD) clock/calendar and 56 bytes of non-volatile SRAM for data storage. The DS1307 communicates via an I2C bus, allowing easy integration into various systems. It supports both 12-hour and 24-hour formats with automatic leap-year adjustments.

With a built-in power-sense circuit, the DS1307 ensures continuous timekeeping even during power failures by switching to a backup supply. This module consumes less than 500nA in battery backup mode, making it ideal for battery-operated devices. Its industrial temperature range of -40°C to +85°C adds versatility for various applications.

The DS1307 Real Time Clock IC finds applications in timers, data loggers, and other electronic projects requiring accurate timekeeping. Explore how this reliable RTC can enhance your designs today.

At DNA, we offer high-quality components from trusted manufacturers like the Brand/Manufacturer. Explore our range of reliable components in the "Components & IC's" category. Check other "Components & IC's" that we have in stock.

If you are looking for specific electronic parts, reach out to us. We can import items not in stock and provide support for both retail and bulk orders. Consider checking out our selection of Development boards, Analog IC, Crystal, Transistor, and more. Contact Us

Features of DS1307 Real Time Clock IC

• Counts Seconds, Minutes, Hours, Date, Month, Day, Year
• 56-Byte Nonvolatile SRAM
• I2C Serial Interface
• Programmable Square-Wave Output
• Automatic Power-Fail Detect
• Low Power Consumption

Specification of DS1307 Real Time Clock IC

• Operating Voltage: 3V to 5.5V
• Current Consumption: <500nA
• Temperature Range: -40°C to +85°C
• Leap-Year Compensation: Yes
• Interface: I2C

Applications of DS1307 Real Time Clock IC

• Timers
• Data Loggers
• Battery-Operated Devices
• Embedded Systems
• Timekeeping in Electronics

Related Links for DS1307 Real Time Clock IC

• Other Products from Components & IC's Category

Package Includes

• 1 X DS1307 Real Time Clock IC
