IR2104 Half Bridge Driver IC

IR2104 Dual MOSFET Half Bridge Driver

IR2104 Dual MOSFET IC, Half Bridge, 10V-20V supply, 360mA output, 150ns delay.

The IR2104 Dual MOSFET Half Bridge Driver is designed for high voltage applications, supporting a supply range of 10V to 20V. It features a floating channel for driving N-channel MOSFETs or IGBTs in high side configurations. With a maximum output current of 360mA and a propagation delay of just 150ns, this driver ensures fast and efficient operation. The IR2104 is compatible with standard CMOS or LSTTL logic, making it versatile for various projects.

Built with proprietary HVIC and CMOS technologies, the IR2104 Dual MOSFET Half Bridge Driver offers rugged durability. It includes undervoltage lockout and cross-conduction prevention logic to enhance safety and performance. This driver is ideal for applications in robotics and motor control, where precise timing and control of power devices are crucial.

Choose the IR2104 for reliable operation in power electronics. Its design ensures that both high and low side outputs are well matched, providing stability in demanding environments. Integrate this driver into your circuit designs for improved efficiency and performance.

Explore the reliability of the IR2104 from a trusted manufacturer at DNA. As part of the MOSFET & IGBT category, this product meets high standards. Check other "MOSFET & IGBT" that we have in stock.

If you're searching for specific electronic components, reach out to us at DNA. We can import parts not available in our stock and support both retail and bulk orders. Consider related items like Digital ICs, MOSFETs, HMI Displays, Microcontrollers, and more. Contact Us

Features of IR2104 Dual MOSFET Half Bridge Driver

• Floating channel for bootstrap operation
• Fully operational to +600V
• Tolerant to negative transient voltages
• Gate drive supply range from 10 to 20V
• Undervoltage lockout
• Cross-conduction prevention logic
• Internally set deadtime
• High side output in phase with input

Specification of IR2104 Dual MOSFET Half Bridge Driver

• Supply Voltage: 10V-20V
• Max Output Current: 360mA
• Propagation Delay: 150ns
• Input Logic Compatibility: 3.3V, 5V, 15V
• Max Voltage: 600V

Applications of IR2104 Dual MOSFET Half Bridge Driver

• Motor control
• Robotics
• Power electronics
• H-Bridge circuits
• High side switching applications

Related Links for IR2104 Dual MOSFET Half Bridge Driver

• Other Products from MOSFET & IGBT Category

Package Includes

• 1 X IR2104 Dual MOSFET Half Bridge Driver IC
