LNK564PN IC AC-DC Offline Switcher IC


Write a review | 0 reviews

  • Stock: 26

    Availability: InStock priceValidUntil: 2026-03-03

  • SKU: 2971 | DAE682

Availability: InStock priceValidUntil: 2026-03-03

  • Rs. 64.90 (inc GST)
    Rs.55.00 + GST

    Qty :

  • Quantity Pricing (inc GST)

    5 + 69.50 15 + 63.96 30 + 58.76

GST Invoice: Available for all purchases — eligible for input tax credit.

Delivery: 2–8 days across India. No MOQ required.

Bulk Orders: Need more quantity or not in stock? Email: dnatechindia [at] gmail.com

Import Service: We import a wide range of electronic components on request.

LNK564PN IC AC-DC Offline Switcher IC

LNK564PN IC for energy-efficient power supplies with high performance, 700V MOSFET, and thermal shutdown.

The LNK564PN IC AC-DC Offline Switcher IC is designed to enhance energy efficiency in power supply applications. This IC replaces traditional linear and capacitor-fed power supplies, providing superior performance at a comparable cost. It integrates a 700V power MOSFET, oscillator, and thermal shutdown circuitry into a single monolithic design, simplifying your power management needs. With features like frequency jittering and cycle-by-cycle current limit, the LNK564PN IC AC-DC Offline Switcher IC ensures reliable operation under varying load conditions.

Ideal for buck and buck-boost converters, this IC derives its start-up and operating power directly from the DRAIN pin, eliminating the need for additional bias supply components. The auto-restart feature protects against faults like short circuits, reducing component count and enhancing system reliability. For Indian customers looking for efficient power solutions, the LNK564PN IC AC-DC Offline Switcher IC offers a practical choice for modern electronic designs.

Whether you are building compact power supplies or enhancing existing systems, the LNK564PN IC AC-DC Offline Switcher IC meets your needs with high performance and energy efficiency. Trust in this reliable component to power your projects effectively.

Explore the efficiency of the LNK564PN IC AC-DC Offline Switcher IC at DNA. Discover top-notch products in the AC DC converter Offline Switcher category. Check other AC DC converter Offline Switcher that we have in stock.

At DNA, we cater to all your electronic component needs. If you can't find specific parts, reach out. We can import items and support both retail and bulk orders. Check our range of related products like Power Supply, Inductor, Diode, MOSFET, LCD, and DC to DC Converter Module. Contact Us.

Features of LNK564PN IC AC-DC Offline Switcher IC

  • Energy-efficient design
  • Integrated 700V power MOSFET
  • Auto-restart fault protection

Specification of LNK564PN IC AC-DC Offline Switcher IC

  • Operating voltage: 700V
  • Integrated thermal shutdown
  • Frequency jittering for stability

Applications of LNK564PN IC AC-DC Offline Switcher IC

  • Power supply circuits
  • Buck and buck-boost converters
  • Energy-efficient devices

Related Links for LNK564PN IC AC-DC Offline Switcher IC

Package Includes

  • 1 X LNK564PN IC AC-DC Offline Switcher IC
Extra Information
Country of Origin China
Imported By ElectroSource Private Limited
