Product Images are shown for illustrative purposes only and may differ from actual product.

Omron G6J-2P-Y DC24 Surface-Mount DPDT Signal Relay

  • Stock: Out Of Stock

    Availability: NotInStock priceValidUntil: 2026-12-17

  • Brand: Omron
  • SKU: 10765 | DAJ853

Availability: NotInStock priceValidUntil: 2026-12-17

  • Rs. 517.19 (inc GST)
    Rs.438.30 + GST
    Qty :

GST Invoice: Available for all purchases; eligible for input tax credit.

Delivery: 2–8 days across India. No MOQ required.

Bulk Orders: Need a larger quantity or item not in stock? Email: dnatechindia [at] gmail.com

Import Service: We import a wide range of electronic components on request.

Omron G6J-2P-Y DC24 Surface-Mount DPDT Signal Relay

Omron G6J-2P-Y DC24 DPDT relay with a 24 VDC coil, sealed structure and PCB terminals.

The Omron G6J-2P-Y DC24 is a DPDT signal relay for switching signals in electronic equipment. Its 24 VDC coil operates a pair of changeover contacts, and its PCB terminals support surface mounting on a circuit board.
The fully sealed structure helps protect the relay’s internal parts. A bifurcated crossbar contact mechanism and Ag (Au-alloy) contacts form the switching design, while improved solder heat resistance supports board assembly. This PCB-terminal relay brings switching into a compact board-level design.
Use it in communication equipment, audio-visual products and industrial equipment where a relay with two changeover contacts is needed.
Find Omron relays and related parts at DNA. Browse our Relay, Relay Socket & SSR range to source components for repair, production and new designs. Check other Relay, Relay Socket & SSR that we have in stock
For Indian electronics buyers, DNA can help source parts you cannot find in our listings, with import support and retail or bulk supply. Ask us about relays, sensors, diodes, SMPS and other components. Contact Us

Features of Omron G6J-2P-Y DC24 Surface-Mount DPDT Signal Relay

  • Fully sealed structure
  • DPDT (2c) contact arrangement
  • Bifurcated crossbar contact mechanism
  • Ag (Au-alloy) contact material
  • Improved resistance to soldering heat

Specifications of Omron G6J-2P-Y DC24 Surface-Mount DPDT Signal Relay

  • Rated coil voltage: 24 VDC
  • Rated coil current: 9.2 mA at 23°C, ±10%
  • Coil power consumption: approximately 230 mW
  • Rated contact load: 0.3 A at 125 VAC or 1 A at 30 VDC, resistive load
  • Maximum switching voltage: 125 VAC or 110 VDC
  • Insulation resistance: 1,000 MΩ min. at 500 VDC
  • Ambient operating temperature: -40 to 85°C, no icing or condensation
  • Dimensions: 10.6 × 5.7 × 9 mm, ±0.3 mm

Applications of Omron G6J-2P-Y DC24 Surface-Mount DPDT Signal Relay

  • Communication equipment
  • Audio-visual products
  • Industrial equipment

Related Links for Omron G6J-2P-Y DC24 Surface-Mount DPDT Signal Relay

Package Includes

  • 1 X Omron G6J-2P-Y DC24 Surface-Mount DPDT Signal Relay
Extra Information
Country of Origin China
Imported By ElectroSource Private Limited
