Raspberry Pi CM3+/16GB Compute Module 3+ System-on-Module

Raspberry Pi CM3+/16GB system-on-module with a BCM2837B0 processor, 1 GB LPDDR2 RAM, 16 GB eMMC flash and a 200-pin SODIMM form factor.

The Raspberry Pi CM3+/16GB is a system-on-module with a BCM2837B0 processor, 1 GB of RAM and 16 GB of on-board eMMC storage. Its 200-pin SODIMM form factor lets designers add Raspberry Pi computing to custom systems and product shapes.
The module combines processing, memory, storage and supporting power circuitry in one unit. It provides GPIO and peripheral interfaces, plus connections for cameras and displays. This gives designers options when they build a custom carrier board and connect system components. It also supports a Linux software stack.
Use this module for embedded design and development, industrial systems and IoT projects. Its integrated computing and storage can help simplify the design of a custom electronic product.
DNA supplies Raspberry Pi components for makers, engineers and product teams across India. Explore this Raspberry Pi module and other products in the category. Check other Raspberry Pi that we have in stock
Buying electronics in India? Contact DNA if you cannot find the part you need. We support imports and retail or bulk orders. You can also ask about HMI displays, connectors, sensors, capacitors and power supplies. Contact Us

Features of Raspberry Pi CM3+/16GB Compute Module 3+ System-on-Module

  • Combines processor, RAM, eMMC storage and supporting power circuitry
  • Supports the ARMv8 instruction set
  • Offers GPIO and multiple peripheral interfaces for custom system design
  • Includes camera and display interface options
  • Supports a Linux software stack

Specifications of Raspberry Pi CM3+/16GB Compute Module 3+ System-on-Module

  • Processor: Broadcom BCM2837B0, up to 1.2 GHz
  • RAM: 1 GB LPDDR2
  • eMMC flash: 16 GB
  • GPIO: 48 pins, with GPIO0–27 and GPIO28–45 available for general use
  • HDMI and USB: HDMI 1.3a and USB 2.0 OTG-capable port
  • Camera and display interfaces: One 2-lane and one 4-lane CSI interface, and one 2-lane and one 4-lane DSI interface
  • SODIMM form factor: 200-pin DDR2 mechanical format
  • Operating temperature: -25 °C to +80 °C nominal

Applications of Raspberry Pi CM3+/16GB Compute Module 3+ System-on-Module

  • Custom systems and form factors
  • Embedded design and development
  • Industrial systems
  • Industrial Internet of Things (IIoT)

Related Links for Raspberry Pi CM3+/16GB Compute Module 3+ System-on-Module

Package Includes

  • 1 X Raspberry Pi CM3+/16GB Compute Module 3+ System-on-Module
Extra Information
Country of Origin China
Imported By ElectroSource Private Limited
