Raspberry Pi SC0915 RP2040 Microcontroller Development Board

SC0915 RP2040 microcontroller development board with dual-core Arm Cortex-M0+ processor up to 133 MHz, 2 MB QSPI flash and 26 GPIO pins.

The Raspberry Pi SC0915 RP2040 microcontroller development board provides a compact platform for firmware and embedded control work. Its dual-core Arm Cortex-M0+ processor runs at up to 133 MHz, with 2 MB of external QSPI flash for program storage.
A range of digital interfaces helps the board connect with peripherals in many designs. Two programmable I/O blocks support custom interface behavior, while the Micro-USB port handles power, data and reprogramming.
Use this RP2040 development board to build and test microcontroller projects. Its programmable I/O can also emulate interfaces such as SD Card and VGA, making the board useful for interface development.
DNA offers Raspberry Pi boards and parts for projects across the Raspberry Pi range. Browse this category to find components for your next build and review product details before you choose. Check other Raspberry Pi that we have in stock
For Indian electronics buyers, DNA offers retail and bulk support, plus import support for parts that are hard to find. Contact us if you need help sourcing a board, Digital IC, Capacitor, DC to DC Converter Module or Connector. Contact Us

Features of Raspberry Pi SC0915 RP2040 Microcontroller Development Board

  • RP2040 platform supports embedded firmware development
  • Multiple digital interfaces support a range of peripheral connections
  • Programmable I/O blocks support custom interface behavior
  • Micro-USB port handles power, data and reprogramming
  • SWD interface supports board-level debugging
  • On-board buck-boost supply provides regulated power from VSYS

Specifications of Raspberry Pi SC0915 RP2040 Microcontroller Development Board

  • Processor: Dual-core Arm Cortex-M0+
  • SRAM: 264 kB on-chip
  • Flash memory: 2 MB external QSPI
  • Exposed GPIO: 26 multifunction pins, fixed at 3.3 V
  • ADC: 12-bit, 500 ksps
  • Digital interfaces: 2 UART, 2 I2C and 2 SPI
  • USB: USB 1.1 via Micro-USB
  • VSYS input voltage: 1.8 V to 5.5 V recommended operating range

Applications of Raspberry Pi SC0915 RP2040 Microcontroller Development Board

  • RP2040 microcontroller development
  • PIO-based emulation of interfaces such as SD Card and VGA

Related Links for Raspberry Pi SC0915 RP2040 Microcontroller Development Board

Package Includes

  • 1 X Raspberry Pi SC0915 RP2040 Microcontroller Development Board
Extra Information
Country of Origin China
Imported By ElectroSource Private Limited
