The TLP2561 is a multi-channel photocoupler (optocoupler) featuring high isolation voltage and a compact surface-mount package. It integrates multiple optically isolated channels with high-speed single-transistor output, providing reliable signal transmission between circuits while maintaining excellent electrical isolation. This device is designed for applications that require space-saving, high-density mounting, and high voltage insulation, such as industrial control systems, inverter circuits, and signal isolation for microcontrollers.

DNA solutions, Nashik has various types of Photocoupler IC's. Check out our complete collection of Photocoupler IC's.

• Multi-channel configuration: Multiple independent optocoupler channels integrated in one package

• Compact SMD package: Suitable for automated assembly

• High collector-emitter voltage: 80 V

• Low input current requirements

• RoHS compliant and halogen-free

Specifications of TLP2561 High Isolation Voltage Single Transistor Type Multi Photocoupler SMD IC

• Isolation voltage: 5000 Vrms

• Forward current: 50 mA

• Rise/Fall time: ~3 μs / 3 μs

• Package type: SMD

• Operating temperature:  –40 °C to +110 °C

Applications of TLP2561 High Isolation Voltage Single Transistor Type Multi Photocoupler SMD IC

• Industrial control

• Inverters and motor drives

• Power supply circuits

• Microcontroller signal isolation

Package Includes

      1 x TLP2561 High Isolation Voltage Single Transistor Type Multi Photocoupler SMD IC
