T1023 Pulse Transformer

T1023 Pulse Transformer

T1023 Pulse Transformer for signal transmission; 1.5 kV isolation voltage; frequency range up to 10 MHz.

The T1023 Pulse Transformer is designed for effective signal transmission in various applications. It features a frequency range of up to 10 MHz and provides 1.5 kV isolation to ensure safety in your circuits. This transformer is ideal for low-power control circuits, camera flashes, and high-power switched-mode power supplies, making it a versatile choice for engineers and hobbyists alike.

With a compact size of 12.83 mm in length and 7.11 mm in width, the T1023 Pulse Transformer fits easily into tight spaces. It operates within a temperature range of 0°C to +70°C, ensuring reliability in various environments. The dual-channel design allows for enhanced functionality in applications like radar systems and ISDN-Pri systems.

Choose the T1023 Pulse Transformer for your electronic projects that require high voltage pulses and isolation. Its unshielded design and low primary impedance of 0.7 Ohms make it suitable for demanding electronic applications. Experience effective performance and reliability with this high-quality transformer.

At DNA, we offer a wide range of components from trusted brands like Pulse in the Components & IC's category. Explore our collection to find essential components for your electronic projects. Check other "Components & IC's" that we have in stock.

If you are searching for specific electronic parts, we can help. Reach out to us for components like IGBT, Power Supply, or MOSFET. We can import items not in stock and support both retail and bulk orders. Contact Us.

Features of T1023 Pulse Transformer

• SMD/SMT termination style
• Dual-channel design
• Unshielded construction
• 0.7 Ohms primary resistance
• Operating temperature range: 0°C to +70°C

Specification of T1023 Pulse Transformer

• Frequency range: 10 MHz
• Isolation voltage: 1.5 kV
• Primary impedance: 0.7 Ohms
• Length: 12.83 mm
• Width: 7.11 mm
• Height: 6.22 mm

Applications of T1023 Pulse Transformer

• Signal transmission
• Low-power control circuits
• Camera flashes
• High-power switched-mode power supplies
• Radar systems

Package Includes

• 1 X T1023 Pulse Transformer
