Product Images are shown for illustrative purposes only and may differ from actual product.

ATMEGA328P-AU SMD Microcontroller


Write a review | 0 reviews

  • Stock: 15

    Availability: InStock priceValidUntil: 2026-05-16

  • Brand: Atmel
  • SKU: 864 | DAB684

Availability: InStock priceValidUntil: 2026-05-16

  • Rs. 204.44 (inc GST)
    Rs.173.25 + GST

    Qty :

GST Invoice: Available for all purchases; eligible for input tax credit.

Delivery: 2–8 days across India. No MOQ required.

Bulk Orders: Need a larger quantity or item not in stock? Email: dnatechindia [at] gmail.com

Import Service: We import a wide range of electronic components on request.

ATMEGA328P-AU SMD Microcontroller

Atmega328 P-Au SMD Microcontroller

Atmega328P-AU SMD Microcontroller is Atmel’s high performance, low power 8-bit AVR ATMega328p-AU microcontroller in SMD package. Atmega328P-Au has 32K of program space. 23 I/O lines, 6 of which are channels for the 10-bit ADC. Runs up to 20MHz with external crystal. Package can be programmed in circuit and 1.8V to 5V operating voltage.

Atmega328 is the same micro-controller that is used in Arduino UNO R3 the only difference is that this is in SMD package. So you can use this micro-controller and load a Arduino bootloader into it and run any Arduino code.

Features of ATMEGA328P-AU SMD Microcontroller

  • 1.8-5.5 Volts operating range
  • Up to 20MHz
  • Part Number: ATMEGA328P-AU
  • 32kB Flash program memory
  • 1kB EEPROM
  • 2kB Internal SRAM
  • 2 8-bit Timer/Counters
  • 1 16-bit Timer/Counter
  • RTC with separate oscillator
  • 6 PWM Channels
  • 8 Channel 10-bit ADC
  • Serial USART
  • Master/Slave SPI interface
  • 2-wire (I2C) interface
  • Watchdog timer
  • Analog comparator
  • 23 IO lines
  • Data retention : 20 years at 85C/ 100 years at 25C

Package Includes

1 x ATMEGA328P-AU SMD Microcontroller

Extra Information
Country of Origin China
Imported By ElectroSource Private Limited
