CS5460 Bi-directional Energy Meter IC


Write a review | 2 reviews

  • Stock: Out Of Stock

    Availability: NotInStock priceValidUntil: 2026-09-23

  • SKU: 978 | DAB565

Availability: NotInStock priceValidUntil: 2026-09-23

  • Rs. 119.18 (inc GST)
    Rs.101.00 + GST

    Qty :

GST Invoice: Available for all purchases; eligible for input tax credit.

Delivery: 2–8 days across India. No MOQ required.

Bulk Orders: Need a larger quantity or item not in stock? Email: dnatechindia [at] gmail.com

Import Service: We import a wide range of electronic components on request.

CS5460 Bi-directional Power/Energy IC

CS5460 Single Phase, Bi-directional Power Energy Monitoring IC.

The CS5460A is a highly integrated power measurement solution which combines two Analog-to-digital Converters (ADCs), high-speed power calculation functions, and a serial interface on a single chip. CS5460 is designed to accurately measure and calculate: Real (True) Energy, Instantaneous Power, IRMS, and VRMS for single phase 2- or 3-wire power metering applications. The CS5460A interfaces to a low-cost shunt resistor or transformer to measure current, and to a resistive divider or potential transformer to measure voltage. The CS5460A features a bi-directional serial interface for communication with a microcontroller and a pulse output engine for which the average pulse frequency is proportional to the real power. The CS5460A has on-chip functionality to facilitate AC or DC system-level calibration.

The “Auto-boot” feature allows the CS5460A to function ‘stand-alone’ and to initialize itself on system power-up. In Auto-boot Mode, the CS5460A reads the calibration data and start-up instructions from an external EEPROM. In this mode, the CS5460A can operate without a microcontroller, in order to lower the total bill-of-materials cost.

Features of CS5460 Energy Meter IC

  • Energy Data Linearity : ±0.1% of Reading over 1000 :1 Dynamic Range.
  • On-Chip Functions : (Real) Energy, I * V, IRMS and VRMS, Energy-to-Pulse Conversion
  • Smart “Auto-boot” Mode from Serial EEPROM Enables Use without MCU.
  • AC or DC System Calibration
  • Mechanical Counter/Stepper Motor Driver
  • Meets Accuracy Spec for IEC 687/1036, JIS
  • Typical Power Consumption <12 mW
  • Interface Optimized for Shunt Sensor
  • V vs. I Phase Compensation
  • Ground-Referenced Signals with Single Supply
  • On-chip 2.5 V Reference (MAX 60 ppm/°C drift)
  • Simple Three-wire Digital Serial Interface
  • Watch Dog Timer
  • Power Supply Monitor
  • Power Supply Configurations VA+ = +5 V; VA- = 0 V; VD+ = +3.3 V to +5 V

Package Includes

1 x CS5460 Bi-directional Energy Meter IC

Extra Information
Country of Origin China
Imported By ElectroSource Private Limited
