SN74LS125AD Buffers & Line Driver

SN74LS125AD Buffers & Line Driver IC

SN74LS125AD Bus Buffers with 3-state outputs; TTL-compatible inputs; Fast switching speeds with 12 ns delay.

The SN74LS125AD Buffers & Line Driver IC is designed for low power consumption, making it ideal for energy-efficient applications. This device features TTL-compatible inputs, ensuring easy integration into existing TTL-based circuits. With quad bus buffers and three-state outputs, it provides flexibility for various digital applications. The high drive capability allows it to manage heavily loaded bus lines effectively.

Operating within a standard TTL voltage range, the SN74LS125AD Buffers & Line Driver offers fast switching speeds with typical propagation delays around 12 ns. This makes it suitable for high-speed digital applications where quick response times are essential. When disabled, its output transistors present a high-impedance state, ensuring that it neither loads the bus nor acts as a driver.

Applications for the SN74LS125AD Buffers & Line Driver IC include digital signal processing and communication systems. Its reliable performance and low power consumption make it a preferred choice for engineers looking to optimize their designs. Explore the benefits of this versatile component in your next project.

Explore the reliable performance of the Texas Instruments in the 7400 Series IC's. At DNA, we provide a range of high-quality components. Check other '7400 Series IC's' that we have in stock.

If you're searching for specific electronic components, reach out to us. We can help you find parts like Humidity & Temperature Sensors, Crystals, Super Capacitors, Microcontrollers, Transistors, and Digital ICs. We also support retail and bulk orders. Contact Us.

Features of SN74LS125AD Buffers & Line Driver IC

• Low Power Consumption
• TTL-Compatible Inputs
• Quad Bus Buffers
• 3-State Outputs
• Fast Switching Speeds
• Wide Operating Voltage Range

Specification of SN74LS125AD Buffers & Line Driver IC

• High-Impedance State Output Leakage Current (IOZ): 20 µA (maximum)
• Power Dissipation: 32 mW (typical)
• Operating Temperature Range: 0°C to 70°C
• Package Type: SOIC-14
• Number of Pins: 14

Applications of SN74LS125AD Buffers & Line Driver IC

• Digital Signal Processing
• Communication Systems
• High-Speed Digital Applications
• Bus Driving
• TTL Logic Integration

Related Links for SN74LS125AD Buffers & Line Driver IC

• Other Products from 7400 Series IC's Category

Package Includes

• 1 X SN74LS125AD Buffers & Line Driver IC
