ADG201A Quad SPST Switch for analog signal control with ±15 V range, low on-resistance, and break-before-make switching.

The ADG201A Quad SPST Switch is a reliable monolithic CMOS device designed for efficient analog signal control. With a signal handling capability of ±15 V, this switch ensures high performance in demanding applications. Its low on-resistance of 60 ohms and minimal leakage current of 0.5 nA typ make it suitable for precision tasks. The ADG201A features break-before-make switching action, ideal for multiplexer applications, ensuring no unintended connections occur during switching.

This switch operates over an extended temperature range of -40ºC to +85ºC, making it versatile for various environments. Its TTL/CMOS compatibility allows for seamless integration into digital systems, enhancing the functionality of your circuits. The ADG201A Quad SPST Switch is a superior choice for engineers looking to maintain signal integrity while optimizing performance.

For applications needing low power dissipation and high-speed switching, the ADG201A is the perfect solution. Its enhanced design minimizes transients when switching digital inputs, ensuring a smooth operation. Explore the potential of the ADG201A Quad SPST Switch in your next project.

Explore the reliable performance of MISC ANALOG IC's from DNA. The ADG201A from a trusted brand is perfect for your analog signal needs. Check other MISC ANALOG IC's that we have in stock.

If you are searching for specific electronic components, DNA can help. We support retail as well as bulk orders and can import parts if they're not available. Check out our range including Analog ICs, Nextion Displays, Sensor Modules, and more. Contact Us.

Features of ADG201A Quad SPST Switch

• Low On-Resistance (60 ohms)
• Break-Before-Make Switching Action
• TTL/CMOS Compatible
• Extended Temperature Range (-40ºC to +85ºC)
• Low Power Dissipation (33 mW)

Specification of ADG201A Quad SPST Switch

• Supply Voltage: 44 V Max
• Analog Signal Range: ±15 V
• Leakage Current: 0.5 nA typ
• Switching Speed: High
• Package Type: 6-Lead DIP/SOIC

Applications of ADG201A Quad SPST Switch

• Multiplexer Applications
• Signal Routing
• Analog Signal Switching
• Low Power Applications
• High-Speed Data Switching

Related Links for ADG201A Quad SPST Switch

• Other Products from MISC ANALOG IC's Category

Package Includes

• 1 X ADG201A Quad SPST Switch
