  • RFID READER MODULE

Product Images are shown for illustrative purposes only and may differ from actual product.

RFID READER MODULE

  • Price :

    Rs.708.00 (inc GST)

    Qty :

GST Invoice on all Purchase. So you will be eligible to take input tax credit.

IF component not in Stock or require more quantity or want to buy in bulk e-mail us your requirements on: dnatechindia "at" gmail.com.

Shipping : Same day dispatch for Most orders if payment done before 4 pm. Delivery Normally takes 2 to 7 working days depending upon your location.

RFID READER MODULE

This is a 125Khz RFID Reader module with in built Antenna. It is a plug and play device with a reading range of 8-10cms. It has TTL output so it can be interfaced directly to any microcontroller, Arduino or Raspberry pi.

This 125Khz RFID reader module with an internal antenna facilitates communication with Read-Only transponders—type UNIQUE or TK5530 via the air interface. The tag data is sent to the host systems via serial (TTL) interface.

The LF module is best suited for applications in Access Control,Time and Attendance, Asset Management, Handheld Readers,Immobilizers, and other RFID enabled applications.



Features:

  • Low-cost method for reading passive RFID EM4100 family transponder tags
  • Reading Distance 5-10cm of the reader
  • 125kHz read frequency
  • TTL serial interface
  • Built in Antenna



Key Specifications:

  • Power requirements     :  5VDC
  • Current Requirement    :  <120mA
  • Communication            :  TTL Serial
  • Operating temp range   : -40 to +185 °F (-40 to +85 °C)
