6 PIN NARROW SIL ROUND PIN IC BASE

6 PIN NARROW SIL ROUND PIN IC BASE

A 6-pin narrow SIL IC base is a small electronic connector that provides a durable and reusable interface for 6-pin ICs. It consists of a narrow plastic body with six round pins arranged in a straight line. The pins are designed to fit into a PCB while holding an IC securely in place. This allows for easy replacement or testing of ICs.

DNA solutions, Nashik has various types of IC Base. Check out our complete collection of  IC Base.

• Compact Design: Narrow body ideal for space-saving layouts

• High Reliability: Secure connections ensure stable electrical performance

• Reusability: Allows ICs to be inserted and removed multiple times

• Round Pins: Provides robust and long-lasting mechanical and electrical contact

• Standard Pin Pitch: Ensures compatibility with standard PCBs and ICs

• Durable Material: Made of high-quality plastic and metal for longevity

• Polarity Notch: Often includes a marking for proper IC orientation

Specifications of 6 PIN NARROW SIL ROUND PIN IC BASE

• Number of Pins: 6

• Pin Type: Round, gold-plated or tin-plated

• Pin Pitch: Typically 2.54 mm

• Body: High-temperature thermoplastic

• Pins: Brass or phosphor bronze with plating

• Dimensions: Narrow format for tight PCB designs

• Current Rating: ~1A

• Operating Temperature: -55°C to +125°C

• Mounting Style: Through-hole

Applications of 6 PIN NARROW SIL ROUND PIN IC BASE

• Prototyping

• Repair and Maintenance

• IC Protection

• PCB Assembly

• Instrumentation

• Education

Package Includes

      1 x 6 PIN NARROW SIL ROUND PIN IC BASE
