HCPL2232 Optoisolator SMD IC

HCPL2232 Dual-Channel Optoisolator SMD IC

HCPL2232 Optoisolator SMD IC for isolating digital signals with 3.75 kVrms isolation and 5 Mbaud data rate.

The HCPL2232 Dual-Channel Optoisolator SMD IC is designed for high-speed digital signal isolation. With an isolation voltage of 3.75 kVrms, it ensures safe and reliable communication in industrial and medical applications. This optocoupler operates at data rates up to 5 Mbaud, making it suitable for fast logic levels. Its built-in Schmitt trigger receivers provide clean signal transitions, reducing noise and enhancing performance.

Ideal for industrial control systems and medical instrumentation, the HCPL2232 excels in environments demanding high common-mode transient immunity of ≥ 10 kV/µs. The compact 8-pin SMD package allows for easy integration into various electronic designs. Whether for switch-mode power supplies or microprocessor isolation, this component meets diverse needs efficiently.

Explore the advantages of the HCPL2232 Dual-Channel Optoisolator SMD IC for your projects. It simplifies designs with totem-pole outputs that eliminate the need for pull-up resistors. Ideal for both retail and bulk purchases, this optoisolator is a reliable choice for electronics in India.

At DNA Solutions, we offer a range of high-quality OptoCouplers & OptoIsolators from leading manufacturers. Explore the HCPL2232 Dual-Channel Optoisolator and see how it can enhance your projects. Check other OptoCouplers & OptoIsolators that we have in stock.

If you need additional electronic components, reach out to us. We can help you find what you’re looking for, including items like DC to DC Converter IC, Programmers, HMI Displays, MOSFETs, and Microcontrollers. We can also import parts if necessary. Contact Us

Features of HCPL2232 Dual-Channel Optoisolator SMD IC

• Dual-channel optocoupler with Schmitt trigger inputs
• Typical data rate: 5 Mbaud
• Isolation voltage: 3.75 kVrms
• Common-mode transient immunity ≥ 10 kV/µs
• Totem-pole outputs, no pull-up resistors required

Specification of HCPL2232 Dual-Channel Optoisolator SMD IC

• Package: 8-pin SMD (SO-8 / PDIP-8)
• Supply voltage VCC: 4.5 V–20 V
• Output current: up to 25 mA
• Propagation delay ≤ 300 ns
• Operating temp: –40 °C to +85 °C

Applications of HCPL2232 Dual-Channel Optoisolator SMD IC

• Isolation of logic signals in industrial control systems
• Medical instrumentation and signal isolation
• Switch-mode power supplies and gate driving
• Microprocessor and bus-interface isolation

Related Links for HCPL2232 Dual-Channel Optoisolator SMD IC

• Other Products from OptoCouplers & OptoIsolators Category

Package Includes

• 1 X HCPL2232 Dual-Channel Optoisolator SMD IC
